Camera
- Image Sensor 2 MP CMOS
- Max. Resolution 1920 (H) × 1080 (V)
- Min. Illumination 0.02 Lux @ (F2.2, AGC ON), 0 Lux with IR
- Shutter TimePAL: 1/25 s to 1/50,000 s; NTSC: 1/30 s to 1/50,000 s
- Day & NightICR
- Angle Adjustment Pan: 0 to 360°, Tilt: 0 to 75°, Rotate: 0 to 360°
- Signal System PAL/NTSC
Lens
- Lens Type Fixed focal lens, 2.8 and 3.6 mm optional
- Focal Length & FOV
2.8 mm, horizontal FOV: 97°, vertical FOV: 54°, diagonal FOV: 113°
3.6 mm, horizontal FOV: 77°, vertical FOV: 43°, diagonal FOV: 90°
- Lens Mount M12
General
- Material: Metal
- Dimension Ø85.1mm × 80 mm (Ø3.4″ x 3.1″)
- WeightMax. 290 g (0.64 lb.)
- Operating Condition -40 °C to 60 °C (-40 °F to 140 °F). Humidity: 90% or less (non-condensation)
- Communication HIKVISION-C
- Language English
- Power: Supply
12 VDC ± 25%, Max. 3.5 W
